  1.  STAZIONI AD ARIA CALDA > JBC

JBC JNA-2B Stazione di rilavorazione ad Aria Calda 70 W

B43532

JBC JNA-2B 230 V. The station includes T260 Pick & Place and the heating elements J125410 with outlet diameter of 1mm and J325410 with outlet diameter of 3mm.

Linea JBC
UM. PZ
Disponibilità bassa
Disponibilità bassa
Generalmente disp. in 15 gg.

Contattaci:

02 4073747
Genera PDF del prodotto Download PDF
€ 2035,00
-5%
€ 1933,25
IVA esclusa
Salva nei preferiti Salva nei preferiti Invia linkInvia link

ALLEGATI

Manuale B43532
Download
Schema soluzione problemi funzionamento B43532
Download
Disegno B43532
Download

SCHEDA PRODOTTO

JBC JNASE-2A High-Precision Hot Air Station 230 V

Precision soldering through hot air, especially for SMDs JNA is the only Hot Air Station to rework, position and remove SMDs without affecting nearby components.

It is perfect for reworking SMDs on areas with minimal separation.

JBC Exclusive System enables the regulation of temperatures and air at very low levels in order to avoid the movement of adjoining components. Makes it the perfect station for easy and high-precision reworking of components as small as 01005, even under the magnifying glass.



SPECIFICATION

  • Nominal power: 70 W
  • Temperature selection: Room temp. 150 - 450 °C / 300 - 840 °F
  • Cool mode: T off. Used to blow air at room temperature
  • Operating temp. range: 10 - 50 ºC / 50 - 122 ºF
  • Air flow regulation: 0.15 - 2.5 SLPM
  • Vacuum: 53% / 397 mmHg / 15.6 inHg
  • Communication connectors: USB-A / USB-B, RJ12 for RS232, Pedal / Stand



PRODUCT COMPOSITION

  • 1 JNAU High-Precision Hot Air Control Unit:

  • 1 NH High-Precision Heater Hose Set:

  • 1 NHS Stand for NH High-Precision Heater Hose Set:

  • 1 J125010 Cartridge Ø 1:

  • 1 T260 Pick & Place Handle:

  • 1 NBC260 Bent Needles & cups for T260:

  • 1 P405 Pedal:
